Blue Sea 6-Circuit ST Blade Fuse Block with Independent Circuits and Cover
Blue Sea 6-Circuit ST Blade Fuse Block with Independent Circuits and Cover
Tin-plated copper clips, clear cover and two jumpers

DESCRIPTION
Six-circuit DC fuse distribution
Organise six independent circuits with a covered ST blade fuse block. Its corrosion-resistant, tin-plated copper fuse clips help reduce heat and improve electrical system efficiency.
The clear insulating cover includes label recesses for Small Format Labels and a holder for spare fuses. Small Format Labels are sold separately. The block accepts ring or snap fork terminals and includes two terminal block jumpers.
Key features
- Six independent circuits for organised DC distribution
- Maximum rating of 30A per circuit or 40A per jumped circuit group, at up to 32V DC
- Clear insulating cover with Small Format Label recesses and a spare fuse holder
- Corrosion-resistant, tin-plated copper fuse clips
- Accepts ring or snap fork terminals; two terminal block jumpers are included
Choose this fuse block to add organised, covered distribution across six independent DC circuits.
SPECIFICATIONS
| Specification | Value |
|---|---|
| Product type | ST blade fuse block |
| Circuits | 6 independent circuits |
| Maximum amperage | 30A per circuit; 40A per jumped circuit group |
| Maximum voltage | 32V DC |
| Fuse clip material | Corrosion-resistant, tin-plated copper |
| Cover | Clear insulating cover with label recesses; spare fuse holder in cover |
| Compatible terminals | Ring or snap fork type |
| Included | Two terminal block jumpers |
| Labels | Circuit labels sold separately; cover accepts Small Format Labels |
| Mounting | 8″ screw [M4] |
| Screw terminal type | #8-32 with captive start lockwasher |
| Weight | 0.16 kg |
| SKU: | BS-5035B |
| Model #: | BS-5035B |
| MPN: | BS-5035B |
| Package weight: | 0.192 kg |
| Package length: | 0.17 m |
| Package width: | 0.1 m |
| Package height: | 0.05 m |
