48V to 48V DC-DC Converters
Isolated Victron Orion-Tr 48/48 converters delivering clean, regulated 48V power for sensitive equipment.
Isolated 48V to 48V DC-DC Converters for Stable, Regulated Power
A 48V battery bank rarely sits at exactly 48V. Its voltage rises during charging and falls as the bank discharges, which can affect sensitive 48V electronics. A 48V to 48V DC-DC converter takes that variable supply and delivers a regulated, adjustable output. Sensitive loads then receive consistent voltage whatever the battery's state of charge. This collection features the Victron Orion-Tr 48/48 isolated range, built for off-grid, marine, commercial and industrial 48V systems.
Why Choose an Isolated Orion-Tr 48/48 Converter
Each Orion-Tr 48/48 model is galvanically isolated, so there is no direct electrical connection between the input and the output. Isolation helps break ground loops and reduces electrical noise passed to connected equipment. It also lets you build a separate output circuit where your installation design calls for one. If you are deciding whether you need isolation, our guide to isolated vs non-isolated DC-DC converters explains the differences in practical terms.
- Regulated, adjustable output: holds a steady 48V supply as battery voltage fluctuates.
- Wide input range: accommodates the normal voltage swing of a 48V battery system.
- Galvanic isolation: separates input and output circuits to help reduce interference and ground loop issues.
- Three current ratings: 2.5A, 6A and 8A models let you match the converter to your load.
- Robust Victron build quality: suited to permanent installation in demanding environments.
Typical Applications
These converters suit 48V telecommunications and networking equipment, marine electronics on 48V vessels, and monitoring or control gear in off-grid homes and tiny homes. They also fit 48V commercial and industrial installations where clean, stable supply voltage matters. For other voltage combinations, browse the full range of DC-DC converters or compare options across our isolated DC-DC converters.
48V to 48V DC-DC Converter FAQs
Which Orion-Tr 48/48 model do I need?
Start by adding up the continuous current draw of the equipment you plan to power. Then allow some headroom. The 2.5A model suits light electronics, the 6A model handles mid-sized loads, and the 8A model supports heavier continuous demand.
Why use a 48V to 48V converter if my battery is already 48V?
Battery voltage varies with charge level and charging activity. A converter keeps the output regulated, which protects voltage-sensitive devices and helps them run consistently.
Can I use this to step 48V down to 12V or 24V?
No. These models output 48V only. You will need a dedicated 48V to 12V or 48V to 24V converter, which you can find in the DC-DC converter range.
Do I need a fuse on the input?
Yes. Correct overcurrent protection and cable sizing are good practice for any DC installation. Always follow the manufacturer's installation instructions.
Order Your Victron 48V Converter Today
Give your 48V equipment the clean, regulated supply it needs. Choose the Orion-Tr 48/48 rating that matches your load and order now to protect your sensitive electronics.
