Blue Sea 12V 2-Circuit Fuse Panel, Gray, IP67 Front
Blue Sea 12V 2-Circuit Fuse Panel, Gray, IP67 Front
ATO/ATC Fuse Protection, Bicoloured Status LEDs & Dimmable Labels
Regular price
$123.55
Availability:
Special Order
View all products from Blue Sea
Guaranteed Safe and Secure Checkout
0
DESCRIPTION
Compact Weatherproof 12V Switch and Fuse Panel for Marine and Off-Grid Consoles
Engineered specifically for exposed environments such as flybridges, open-cockpit vessels, and external 4WD canopy consoles, this two-circuit fuse and switch panel delivers dependable 12V DC circuit control and overcurrent protection. By integrating ATO/ATC fuse holders with weather-resistant switching and intuitive LED monitoring, it provides a clean, reliable solution for managing essential auxiliary loads where moisture and salt spray are constant hazards.
Unlike standard unsealed switch panels that quickly succumb to corrosion and contact failure when exposed to the elements, the Blue Sea Systems 4302B is purpose-built to endure harsh marine and outdoor conditions. It eliminates the guesswork during electrical troubleshooting and preserves night vision during low-light operation.
Key Features & Technical Benefits
- IP67 Watertight Front Panel: When properly installed using a watertight mounting gasket, the front face is protected against dust ingress and temporary immersion up to 1m for 30 minutes.
- Bicoloured LED Status Indicators: Visual monitoring displays red when a circuit is switched OFF, green when powered ON, and extinguishes completely to immediately indicate a blown fuse or lack of main power.
- Independent Label Backlighting: Features a dedicated backlighting circuit that supports remote switching and dimming, allowing seamless integration with existing dash or helm illumination systems.
- Standard ATO/ATC Fuse Protection: Utilises widely available automotive and marine blade fuses for straightforward circuit protection and simple field replacement.
- Four-Orientation Mounting: Versatile housing design allows installation vertically, horizontally, or inverted to suit tight console layouts and custom dash configurations.
Advanced Circuit Monitoring and Illumination
Managing critical 12V accessories such as bait pumps, washdown systems, navigation lights, or work lights requires instant visual feedback. The integrated bicoloured LEDs simplify fault-finding at the helm. If an indicator fails to illuminate in either switch position, operators immediately know the fuse has blown or the panel is not receiving primary power, significantly reducing diagnostic time in challenging conditions.
For night navigation or off-road driving, glare from overly bright dashboard switches can impair operator vision. The independent label-backlighting circuit allows you to wire the panel's labels into a central dimmer switch, ensuring clear circuit identification without blinding glare.
Installation Considerations and Risk Reduction
Installing unsealed electrical distribution components in open cockpits or external utility boxes creates a high risk of short circuits, parasitic voltage drops, and premature system failure. This panel mitigates these risks by sealing the critical switching interface at the front of the helm. Please note that the IP67 rating applies strictly to the front of the panel when correctly fitted with a watertight mounting gasket; rear wiring connections remain exposed behind the dash and must be installed in a dry cavity or protected appropriately.
Upgrade Your Helm or Console Electrical Control
Ensure reliable switching and overcurrent protection for your auxiliary 12V equipment in exposed environments. Add this weatherproof 2-circuit fuse panel to your marine or off-grid electrical setup today for clean, long-lasting circuit management.
SKU: BS-4302B
SPECIFICATIONS
| Specification | Details |
|---|---|
| Product type | Fuse panel |
| Voltage | 12VDC |
| Number of circuits | 2 |
| Compatible fuse formats | ATO and ATC |
| Front protection | IP67 when properly mounted with a watertight mounting gasket; protected against immersion up to 1 meter for 30 minutes |
| Fuse monitoring | Bicolored LEDs indicate OFF (red), ON (green), or blown (no color) circuits |
| Label backlighting | Independent circuit for remote switching and dimming |
| Mounting orientations | Four |
| Applications | Flybridge and open cockpit |
| Color | Gray |
| SKU: | BS-4302B |
| Model #: | BS-4302B |
| MPN: | BS-4302B |
| Package weight: | 0.42 kg |
| Package length: | 0.16 m |
| Package width: | 0.12 m |
| Package height: | 0.1 m |
WARRANTY
Blue Sea Warranty Policy
Blue Sea Systems products sold by us are supplied with a warranty against defects for the warranty period shown below, subject to the product type, application and the terms of this warranty policy.
The express warranty provided by us is limited to a maximum of 5 years from the original date of purchase, unless otherwise required under Australian Consumer Law.
Blue Sea Systems may offer longer manufacturer support on some products at their discretion
Warranty Lengths by Product Range
| Blue Sea Product Range | Warranty Length | Application / Notes |
|---|---|---|
| Most Blue Sea Systems Products | 5 years | Applies to most Blue Sea Systems products found to be defective in materials or manufacture. |
| P12 Battery Chargers | 5 years | Warranty period starts from the original date of purchase. |
| P12 Remote Displays | 5 years | Warranty period starts from the original date of purchase. |
| Digital Meters | 3 years | Warranty period starts from the original date of purchase. |
| Vessel System Monitors | 3 years | Warranty period starts from the original date of purchase. |
Warranty Assessment and Remedy
If a Blue Sea Systems product is found to be defective in materials or manufacture within the applicable warranty period, we will, at our discretion, arrange a repair, replacement, store credit or refund, depending on the nature of the fault and the requirements of Australian Consumer Law.
Products may need to be returned for assessment before a warranty claim can be approved. Where required, the product must be returned with dated proof of purchase and a clear description of the fault.
Labour costs for removing, replacing, reinstalling or diagnosing a product are not covered by this express warranty unless otherwise required under Australian Consumer Law.
Making a Warranty Claim
To make a warranty claim, please contact us with your dated proof of purchase, product details and a description of the fault.
The product may need to be returned for inspection before the claim can be assessed. If the product is confirmed to be faulty and covered by this warranty, we will advise the available remedy.
What This Warranty Does Not Cover
This warranty does not cover faults or damage caused by incorrect installation, incorrect application, misuse, abuse, neglect, unauthorised modification, accidental damage, normal wear and tear, environmental damage, or failure to use the product in accordance with the manufacturer's instructions.
- Incorrect installation or wiring
- Incorrect product selection or application
- Misuse, abuse or neglect
- Physical or accidental damage
- Water ingress or environmental damage outside the product's intended use
- Unauthorised modification or repair
- Normal wear and tear
- Labour costs for removal, replacement, reinstallation or diagnosis
- Freight, travel or call-out costs unless otherwise required by law
- Products not returned for assessment when reasonably required
Manufacturer Support
Blue Sea Systems may provide additional manufacturer support on some products beyond the warranty period listed above. Where available, we may assist customers in contacting the manufacturer, but any manufacturer support beyond the express warranty period is subject to the manufacturer's own terms and continued availability.
Australian Consumer Law
This warranty is in addition to other rights and remedies available at law. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
