Blue Sea 10A ON-OFF Red Stainless Steel Switch Button
Blue Sea 10A ON-OFF Red Stainless Steel Switch Button
Marine-Grade Body with Illuminated LED Ring & Rear Spade Terminals
Regular price
$51.48
Availability:
Special Order
View all products from Blue Sea
Guaranteed Safe and Secure Checkout
0
DESCRIPTION
Reliable Tactile Control with Integrated LED Status Indication
Managing auxiliary circuits in demanding environments requires switchgear that combines structural durability with clear visual feedback. This latching push button switch provides a definitive ON-OFF control point rated up to 10A, making it an ideal choice for custom dashboards, marine helms, and off-grid power canopies. Unlike standard plastic switches that can become brittle, fade under UV exposure, or fail due to moisture and salt spray, the marine-grade stainless steel body offers exceptional resistance to corrosion and physical wear. This robust build reduces the risk of mechanical failure when operating critical equipment in harsh Australian conditions.
High-Visibility Illumination for Low-Light Operation
Navigating a control panel in the dark or during poor weather can lead to accidental activation of the wrong circuit. To solve this problem, the actuator features an integrated red LED ring that delivers immediate, unmistakable status indication. Whether wired to illuminate when the circuit is active or configured as a permanent dash backlight for night-time visibility, the distinct red glow allows operators to quickly identify the control point at a glance. The flush-profile button design not only provides a clean, modern aesthetic for custom panels but also helps prevent accidental knocks in tight cab or helm spaces.
Key Features and Benefits
- Marine-Grade Stainless Steel Body: Delivers superior corrosion resistance and longevity in coastal, marine, and high-vibration automotive environments.
- Integrated Red LED Ring: Provides clear visual status feedback and effortless switch location in low-light conditions.
- Secure Through-Panel Mounting: Features a precision-threaded barrel housing and included hex mounting nut for a stable, rattle-free installation.
- Standard Rear Spade Terminals: Equipped with male spade connectors at the rear for straightforward wiring of both the switching circuit and the LED illumination.
- Latching Action: Offers positive tactile feedback when transitioning between active and inactive circuit states.
Streamlined Installation for Custom Dashboards and Panels
Designed for both professional auto electricians and DIY enthusiasts, this push button switch simplifies the wiring and fitting process. The threaded housing passes cleanly through a standard circular panel cut-out, eliminating the need for complex rectangular notches required by traditional rocker switches. Once positioned, the supplied hex nut secures the unit firmly against the fascia, preventing rotation or loosening over corrugated tracks or rough seas. At the rear, standard male spade terminals allow for quick connection using common female crimp connectors, streamlining integration into existing wiring harnesses.
Versatile Applications Across Marine and Mobile Setups
With its clean architectural finish and dependable electrical performance, this control switch is suited to a wide variety of low-voltage setups, including:
- Marine helm panels, bilge pump overrides, and navigation light controls
- 4WD dashboards, dual-battery canopy systems, and auxiliary driving light triggers
- Caravan, camper trailer, and motorhome interior lighting or water pump circuits
- Industrial equipment enclosures and custom machinery control boxes
Upgrade Your Control Panel
Equip your vessel, vehicle, or off-grid system with dependable, corrosion-resistant switchgear. Add this illuminated stainless steel push button switch to your cart today for a clean, professional panel installation.
SKU: BS-4162B
SPECIFICATIONS
| Specification | Value |
|---|---|
| Product type | Switch button |
| Rated current | 10A |
| Switching function | ON-OFF |
| Material | Stainless steel |
| Colour | Red |
| SKU: | BS-4162B |
| Model #: | BS-4162B |
| MPN: | BS-4162B |
| Package weight: | 0.024 kg |
| Package length: | 0.03 m |
| Package width: | 0.03 m |
| Package height: | 0.06 m |
WARRANTY
Blue Sea Warranty Policy
Blue Sea Systems products sold by us are supplied with a warranty against defects for the warranty period shown below, subject to the product type, application and the terms of this warranty policy.
The express warranty provided by us is limited to a maximum of 5 years from the original date of purchase, unless otherwise required under Australian Consumer Law.
Blue Sea Systems may offer longer manufacturer support on some products at their discretion
Warranty Lengths by Product Range
| Blue Sea Product Range | Warranty Length | Application / Notes |
|---|---|---|
| Most Blue Sea Systems Products | 5 years | Applies to most Blue Sea Systems products found to be defective in materials or manufacture. |
| P12 Battery Chargers | 5 years | Warranty period starts from the original date of purchase. |
| P12 Remote Displays | 5 years | Warranty period starts from the original date of purchase. |
| Digital Meters | 3 years | Warranty period starts from the original date of purchase. |
| Vessel System Monitors | 3 years | Warranty period starts from the original date of purchase. |
Warranty Assessment and Remedy
If a Blue Sea Systems product is found to be defective in materials or manufacture within the applicable warranty period, we will, at our discretion, arrange a repair, replacement, store credit or refund, depending on the nature of the fault and the requirements of Australian Consumer Law.
Products may need to be returned for assessment before a warranty claim can be approved. Where required, the product must be returned with dated proof of purchase and a clear description of the fault.
Labour costs for removing, replacing, reinstalling or diagnosing a product are not covered by this express warranty unless otherwise required under Australian Consumer Law.
Making a Warranty Claim
To make a warranty claim, please contact us with your dated proof of purchase, product details and a description of the fault.
The product may need to be returned for inspection before the claim can be assessed. If the product is confirmed to be faulty and covered by this warranty, we will advise the available remedy.
What This Warranty Does Not Cover
This warranty does not cover faults or damage caused by incorrect installation, incorrect application, misuse, abuse, neglect, unauthorised modification, accidental damage, normal wear and tear, environmental damage, or failure to use the product in accordance with the manufacturer's instructions.
- Incorrect installation or wiring
- Incorrect product selection or application
- Misuse, abuse or neglect
- Physical or accidental damage
- Water ingress or environmental damage outside the product's intended use
- Unauthorised modification or repair
- Normal wear and tear
- Labour costs for removal, replacement, reinstallation or diagnosis
- Freight, travel or call-out costs unless otherwise required by law
- Products not returned for assessment when reasonably required
Manufacturer Support
Blue Sea Systems may provide additional manufacturer support on some products beyond the warranty period listed above. Where available, we may assist customers in contacting the manufacturer, but any manufacturer support beyond the express warranty period is subject to the manufacturer's own terms and continued availability.
Australian Consumer Law
This warranty is in addition to other rights and remedies available at law. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
