Anderson Plugs & Connectors

Genuine Anderson Plugs and High-Current DC Connectors

A reliable 12V or 24V system depends on its connections. A plug or feed through that is undersized or poorly sealed can cause voltage drop, heat build-up and intermittent faults. This range covers genuine Anderson plug connectors, flush mount Anderson sockets, dust covers and 250A battery feed through posts. These parts suit caravans, RVs, 4WDs, camper trailers, boats, trucks and off-grid builds.

Genuine Anderson Plug Connectors from 50A to 350A

Anderson connectors are a common choice for quick-disconnect DC power. Typical uses include:

• Linking a trailer battery to a tow vehicle
• Connecting portable solar to an RV
• Running fridges, compressors and battery boxes

The genuine plugs in this collection come in four ratings. Each includes contacts sized to suit its cable:

• 50A with 6AWG contacts: available in grey, red and blue. Suits drawbar, solar input and accessory circuits.
• 120A with 2AWG contacts: grey. Suits heavier battery-to-battery links and higher-draw loads.
• 175A with 0AWG contacts: grey. Suits large battery banks and high-current charging leads.
• 350A with 00AWG contacts: grey. Suits heavy-duty industrial, commercial and truck applications.

Anderson housings only mate with the same colour. This lets you key separate circuits so the wrong leads cannot be joined by mistake.

Flush Mount Anderson Panels and Dust Covers

Flush mount panels give a neat, recessed connection point on a canopy, battery box, drawbar or bulkhead. Two layouts are available:

• A single or dual 50A Anderson panel, supplied with grey plugs
• A combination panel with a 50A Anderson, cigarette socket, USB and USB-C outlets

Dust covers are available for 50A, 120A and 175A plugs, including black rubber options. They help keep dust, mud and moisture off the contacts on the tracks or on deck.

250A Battery Feed Through Connectors

Feed through connectors pass heavy cable cleanly through a battery box, cabinet or bulkhead without exposing live terminals. Two styles are available:

• 250A bulkhead M10 battery posts in red and black, each with a protective boot
• Blue Sea 250A terminal feed through connectors with 5/16 studs, in red and black for clear polarity identification

Terminate cables at these posts with correctly sized crimp cable lugs. Where several circuits need to share one feed, distribute power through DC bus bars and studs.

Installation and Setup Considerations

Choose an Anderson rating and contact size that suit your cable gauge and the continuous current of the circuit, not just the peak load. Our DC cable sizing and system wiring calculator helps you work out cable size for your run length and current. You can then match it to the 6AWG, 2AWG, 0AWG or 00AWG contacts listed above.

When installing:

• Crimp contacts and lugs firmly with the correct tool.
• Fit boots and dust covers on exposed connections.
• Keep red and black feed throughs consistent with your system polarity.

Build a tidy, serviceable DC system with genuine Anderson plugs and purpose-built feed through hardware. Select your rating, add matching dust covers, and order today to secure your next caravan, 4WD or marine wiring job.
