Victron Cyrix-Li-Intelligent Charge Relay 24/48V-230A

230A Continuous, IP54, BMS-Controlled Charge Disconnect for 24V/48V Systems


Regular price $275.22
$305.80
/
Availability: Special Order
View all products from Victron
Guaranteed Safe and Secure Checkout
Apple Pay Google Pay MastercardPayPalShop Pay Visa

0
Victron Cyrix-Li-charge 230A relay with blue status LED and heavy-duty threaded bolt terminal

Victron Cyrix-Li-Intelligent Charge Relay 24/48V-230A

DESCRIPTION

Victron Cyrix-Li-Charge 24/48V-230A: Intelligent Charge Relay for LiFePO4 Battery Systems

Precision Charge Control for Victron Lithium Battery Installations

The Victron Cyrix-Li-Charge 24/48V-230A is a microprocessor-controlled intelligent charge relay designed to integrate seamlessly with Victron VE.Bus BMS and LiFePO4 lithium batteries. It provides a reliable secondary layer of protection by managing the connection of high-current chargers, preventing cell overvoltage and over temperature conditions that can compromise battery lifespan and safety.

Unlike generic contactors or solenoids, the Cyrix-Li-Charge actively monitors both the BMS control signal and system voltages, ensuring chargers are only connected when safe. This reduces the risk of lithium battery damage and improves overall system reliability in 24V and 48V off-grid, marine, and automotive applications.

How the Cyrix-Li-Charge Protects Your Investment

In a Victron lithium system, the VE.Bus BMS acts as the primary safeguard. However, not all chargers can be directly controlled by the BMS. The Cyrix-Li-Charge bridges this gap by acting as a remote-controlled switch that engages or disengages the charger based on BMS commands and voltage thresholds.

  • Immediate disconnection when the BMS signals cell overvoltage or high temperature, preventing irreversible cell damage.
  • Automatic reconnection with a 3-second delay once conditions normalise, minimising downtime.
  • Voltage-sensing logic ensures the charger is only connected when it is actively producing charge voltage (27.4V or 54.8V), avoiding unnecessary cycling.
  • Built-in transient voltage suppression protects against voltage spikes during disconnection, safeguarding sensitive electronics.

Key Features and Benefits

  • High continuous current rating: 230A at 24V, 80A breaking capacity at 48V, suitable for large charger banks and inverter/chargers.
  • Low power consumption: Draws less than 4mA when open, preserving battery charge during storage.
  • IP54 protection: Resistant to dust and water splashes, ideal for engine rooms and exposed installations.
  • LED status indicator: Provides clear visual feedback on relay state (engaged, disengaged, connecting, alarm).
  • Compact and lightweight: 65 x 100 x 50mm, 0.27kg, easy to mount in tight spaces.
  • 3/8"-16 (Approx. M10) stud terminals accept heavy-duty lugs for secure, low-resistance connections.

Engineered for Demanding Environments

The Cyrix-Li-Charge is built to withstand the rigours of mobile and marine installations. Its sealed design (IP54) and robust terminals ensure reliable operation despite vibration, humidity, and temperature fluctuations. The included 1-metre control cable simplifies connection to the VE.Bus BMS, reducing installation time and potential wiring errors.

For system designers and installers, this relay eliminates the need for complex external control circuits, providing a plug-and-play solution that maintains the integrity of Victron's lithium ecosystem.

Applications

  • Marine lithium battery systems with high-output alternators or shore power chargers.
  • Off-grid solar installations using Victron inverter/chargers and MPPT controllers.
  • RV and caravan power systems requiring automated charge disconnect for lithium batteries.
  • Industrial backup power where battery safety and longevity are critical.

Take Control of Your Lithium Charging

Integrate the Victron Cyrix-Li-Charge 24/48V-230A into your energy system to ensure your lithium batteries are charged safely and efficiently. Add to your order today and build a more resilient power solution.


SKU: Vic-CYR020230430

SPECIFICATIONS

Specifications

ModelCyrix-Li-Charge 24/48V-230A
Product CodeCYR020230430
Product TypeIntelligent Charge Relay
Continuous Current And Breaking Capacity At 24 V230 A
Breaking Capacity At 48 V80 A
LED Status IndicationYes
Control CableIncluded (Length 1 m)
Control InputThe Cyrix engages when the control input is high (approx. Battery voltage). The Cyrix disengages when the control input is left free floating or pulled low.
Connect Voltage26.0 V / 52.0 V or more
Battery Terminal Voltage For Engagement2 V or more
Battery Charger Connection Delay3 seconds
Current Consumption When Open<4 mA
Protection CategoryIP54
Weight kg (lbs)0.27 (0.6)
Dimensions H x W x D In mm (h x w x d in inches)65 x 100 x 50 (2.6 x 4.0 x 2.0)

SKU: Vic-CYR020230430
Barcode: 8719076022282
Model #: CYR020230430
MPN: CYR020230430

WARRANTY

Victron Energy Limited Warranty Policy

Direct Customers

Victron Energy provides the following warranty to any direct customer (OEM, distributor or dealer) in relation to any products that Victron Energy has directly sold to the direct customer. This warranty is not an end-user warranty between Victron Energy and an end-user, and end-users shall not have any rights or remedies under this limited warranty towards Victron Energy directly. The direct customer shall, in turn, ensure that the end-user is provided with a warranty identical to this warranty, subject to applicable local mandatory law.

End-Users

Victron Energy may also provide a warranty directly to end-users, in which case the below warranty conditions equally apply to such warranty. In that case, end-users shall claim their warranty at their place of purchase or through the original direct customer of Victron, which can be found through the support section on Victron’s website https://www.victronenergy.com/support. Hence, the direct customer shall on behalf of Victron Energy deal with any warranty claims made under any warranty that Victron Energy may provide directly to end-users. This support section on Victron’s website https://www.victronenergy.com/support will provide further guidance on the procedure for end-users to make a claim under this limited warranty.

If the end-user is a consumer – a natural person who is acting for purposes which are outside that person's trade, business, craft or profession – the following applies. The rights and remedies granted to the consumer under this limited warranty are without prejudice to the consumer’s statutory rights. Furthermore, the consumer is entitled by law to remedies from the seller free of charge in the event of a lack of conformity of the goods (such as repair, replacement, price reduction or rescission), which remedies are not affected by this limited warranty.

Warranty

Victron Energy warrants its products to be free from defects in workmanship and materials for a period of 5 years from the date of purchase by the original end-user, with a maximum of 66 months from the Victron Energy invoice date. Exceptions on this are: lead-acid batteries: 2 years from date of purchase by the original end-user, with a maximum of 30 months from the Victron Energy invoice date, Lithium batteries: 3 years from date of purchase by the original end-user, with a maximum of 42 months from the Victron Energy invoice date. In addition to this, proof of correct battery usage is required when making a battery warranty claim.

For a 10% surcharge on the current net price for products that came with a 5-year warranty, an additional 5 years of warranty can be purchased by Victron’s direct customers, bringing the total warranty to 10 years. Warranty extensions need to be applied for ultimately one year before the expiration of the original term. Victron may ask proof that the product was still functional at the time of purchase of the extended warranty.

During the warranty period, Victron Energy will, at its discretion, repair, replace or (partly) credit the defective product free of charge. The warranty does not include performing or reimbursing de‐installation, transportation, and re‐installation.

This warranty will be considered void if the unit has suffered any physical damage or alteration, either internally or externally, and does not cover damages arising from improper use like:

  • Reversed battery polarity.
  • Inadequate connection.
  • Mechanical shock or deformation.
  • Contact with liquid or oxidation by condensation.
  • Use in an inappropriate environment (dust, corrosive vapour, humidity, high temperature, biological infestation, etc.).
  • Breakage or damage due to lightning.
  • Connection terminals and screws destroyed or other damages, like overheating, due to insufficient tightening.
  • For any electronic breakage except due to lightning (reverse polarity, over‐voltage due to external cause), the state of the internal control diode and/or the input/output X and Y capacitors determine the warranty.

This warranty will not apply where the product has been misused, neglected, improperly installed, or repaired by anyone other than Victron Energy or one of its authorized Repair Centres. In order to qualify for the warranty, the product must not be disassembled or modified.

This warranty and our warranty obligations thereunder (repair, replacement or credit) are the direct customer’s and, if applicable, the end-user’s sole rights and remedies and our sole obligations with respect to any defective and/or non-conforming product or breach of warranty and is subject to and without prejudice to the limitations of liability in this warranty.

Victron Energy shall not be liable for damages, whether direct, incidental, special, or consequential, even caused by negligence or fault.

As a product requires service, it must be brought back to the place of purchase. In case no contact can be made with the merchant, or if he is either unable or not allowed to provide service, direct contact should be made with Victron Energy through the support section on Victron’s website.

In case Victron Energy replaces a product, it will own the replaced product. Victron Energy owns all parts removed from repaired products. Victron Energy uses new or reconditioned parts made by various manufacturers when performing warranty repairs or building replacement products.

If Victron Energy repairs or replaces a part of a product, its warranty term is not extended: the warranty will apply for the remaining term of the original warranty term. For example, if Victron Energy replaces a product with a 5-year warranty after 3 years, the warranty of this product will apply for another 2 years, with a minimum of 6 months.

All remedies and the measure for damages are limited to the above. Victron Energy shall in no event be liable for consequential, incidental, contingent or special damages, even if having been advised of the probability of such damages.

The foregoing limited warranty provided by Victron Energy is in lieu of any other warranties, express or implied arising by law, course of dealing, course of performance, usage of trade or otherwise, of any kind whatsoever including, without limitation, warranties of merchantability or fitness for a particular purpose, with respect to any product. The above is without prejudice to the arrangement for consumers detailed above.

Life Support Policy

As a general policy, Victron Energy does not recommend the use of any of its products in life support applications where failure or malfunction of Victron Energy's product can be reasonably expected to cause the failure of the life support device or to significantly affect its safety or effectiveness. Victron Energy does not recommend the use of any of its products in direct patient care. Victron Energy will not knowingly sell its products for use in such applications unless it receives in writing assurances satisfactory to Victron Energy that the risks of injury or damage have been minimized, the customer assumes all such risks, and the liability of Victron Energy is adequately protected under the circumstances.

Warranty on repairs for products outside their warranty period

The warranty period on products that are outside their warranty period and have been repaired by Victron Energy or one of the Victron Energy Repair centres is six (6) months from delivery. The same applies to spare parts and circuit boards that have been supplied or repaired by Victron Energy.

Transport

It is the responsibility of the sender to sufficiently package these products. The transport must be organized in a way to avoid any damage, especially when a single unit or heavy unit is sent.

Severability

If a part of the terms and conditions of this warranty is held invalid, void or unenforceable due to any particular national or international legislation, it shall not affect other parts of the terms and conditions of this warranty.

Applicable law

This warranty is exclusively governed by the laws of the Netherlands, to the exclusion of the UN Convention on Contracts for the International Sale of Goods.

Contact details

Victron Energy B.V. | De Paal 35, 1351 JG Almere, The Netherlands | https://www.victronenergy.com/support
