Victron 48V 30A BlueSolar PWM-Light Solar Charge Controller

Programmable Load Output with Lighting Timer and Three-Stage 48V PWM Charging


Regular price $149.49
$78.10
/
Availability: Special Order
View all products from Victron
Guaranteed Safe and Secure Checkout
Apple Pay Google Pay MastercardPayPalShop Pay Visa

0
Front view of black and blue Victron BlueSolar PWM solar charge controller showing terminal blocks and interface

Victron 48V 30A BlueSolar PWM-Light Solar Charge Controller

DESCRIPTION

Victron BlueSolar PWM-Light 48V 30A Solar Charge Controller: Reliable PWM Charging with Intelligent Load Control

Efficient 48V Solar Regulation for Off-Grid and Backup Systems

The Victron BlueSolar PWM-Light 48V 30A Solar Charge Controller delivers dependable PWM (Pulse Width Modulation) charging for 48V battery systems, combining straightforward operation with essential load management features. Designed for small to medium off-grid solar installations, this controller ensures your batteries are charged efficiently while protecting them from over-discharge through its integrated low voltage disconnect.

Unlike generic PWM controllers, the BlueSolar PWM-Light series incorporates Victron’s proven three-stage charging algorithm (bulk, absorption, float), optimised for 48V lead-acid and lithium (LiFePO4) batteries. This extends battery lifespan and maximises usable capacity, reducing the risk of premature battery failure in remote or unattended systems.

Smart Load Output with Lighting Control

A standout feature is the programmable load output, which can be configured for manual control, low voltage disconnect, or automated lighting schedules. The intuitive two-digit seven-segment display allows quick setup of timer functions, making it ideal for controlling 12V/24V DC lights (via a DC-DC converter) or other loads directly from the controller. This eliminates the need for separate timers or relays in many applications.

The load output is protected against overload and short circuit, with automatic shutdown after 60 seconds at 130% load or 5 seconds at 160% load, and immediate shutdown on short circuit. This robust protection reduces the risk of damage to connected equipment and wiring.

Built for Harsh Australian Conditions

Engineered to operate at full load in temperatures from -20°C to +50°C, the BlueSolar PWM-Light is well-suited to the Australian climate. Its IP20 protection rating is designed for indoor or protected enclosure mounting, keeping the compact unit (95 x 140 x 33.5 mm) safe from dust and moisture ingress. The controller also features reverse polarity protection on both the solar array and battery connections, preventing accidental damage during installation.

Key Features

  • Three-stage PWM charging (bulk, absorption, float) for 48V batteries
  • Programmable load output with low voltage disconnect and lighting timer
  • Two-digit seven-segment display for easy configuration of load settings
  • Comprehensive electronic protection: overload, short circuit, reverse polarity, and over-temperature
  • Wide operating temperature range (-20°C to +50°C) for reliable performance in extreme conditions
  • Ultra-low self-consumption (< 10 mA) minimises battery drain when idle
  • Common positive grounding compatible with many existing systems
  • Compact and lightweight (0.17 kg) for easy installation in enclosures

Applications

This charge controller is an excellent choice for:

  • Remote off-grid cabins and sheds requiring reliable 48V battery charging
  • Solar-powered lighting systems with automated day/night timing
  • Telecommunications and monitoring equipment in isolated locations
  • Backup power systems where battery health is critical
  • Small-scale renewable energy projects needing a cost-effective, durable controller

With its combination of proven Victron reliability, essential load control, and straightforward operation, the BlueSolar PWM-Light 48V 30A controller is a smart investment for maintaining your off-grid power system. Add one to your solar setup today and experience worry-free battery management.


SKU: VIC-SCC040030050

SPECIFICATIONS

Specifications

Battery Voltage48V
Rated charge current30A
Automatic load disconnectYes
Maximum solar voltage100 V
Self-consumption< 10 mA
Load outputManual control + low voltage disconnect
ProtectionBattery reverse polarity (fuse)
ProtectionOutput short circuit
ProtectionOver temperature
Overload protectionShut down after 60 s in case of 130% load
Overload protectionShut down after 5 s in case of 160% load
Overload protectionShort circuit: immediate shut down
GroundingCommon positive
Operating temp. range-20 to +50°C (full load)
Humidity (non-condensing)Max 95%
Bulk charge58.0V
Charge voltage 'absorption'56.8V
Charge voltage 'float'55.2V
Low voltage load disconnect44.8V
Low voltage load reconnect50.4V (manual) 52.4V (automatic)
Protection classIP20
Terminal size6 mm² / AWG10
Weight0.17 kg
Dimensions (h x w x d)95 x 140 x 33.5 mm
SafetyIEC 62109-1
EMCEN 61000-6-1, EN 61000-6-3

SKU: VIC-SCC040030050
Barcode: 8719076046257
Model #: SCC040030050
MPN: SCC040030050

WARRANTY

Victron Energy Limited Warranty Policy

Direct Customers

Victron Energy provides the following warranty to any direct customer (OEM, distributor or dealer) in relation to any products that Victron Energy has directly sold to the direct customer. This warranty is not an end-user warranty between Victron Energy and an end-user, and end-users shall not have any rights or remedies under this limited warranty towards Victron Energy directly. The direct customer shall, in turn, ensure that the end-user is provided with a warranty identical to this warranty, subject to applicable local mandatory law.

End-Users

Victron Energy may also provide a warranty directly to end-users, in which case the below warranty conditions equally apply to such warranty. In that case, end-users shall claim their warranty at their place of purchase or through the original direct customer of Victron, which can be found through the support section on Victron’s website https://www.victronenergy.com/support. Hence, the direct customer shall on behalf of Victron Energy deal with any warranty claims made under any warranty that Victron Energy may provide directly to end-users. This support section on Victron’s website https://www.victronenergy.com/support will provide further guidance on the procedure for end-users to make a claim under this limited warranty.

If the end-user is a consumer – a natural person who is acting for purposes which are outside that person's trade, business, craft or profession – the following applies. The rights and remedies granted to the consumer under this limited warranty are without prejudice to the consumer’s statutory rights. Furthermore, the consumer is entitled by law to remedies from the seller free of charge in the event of a lack of conformity of the goods (such as repair, replacement, price reduction or rescission), which remedies are not affected by this limited warranty.

Warranty

Victron Energy warrants its products to be free from defects in workmanship and materials for a period of 5 years from the date of purchase by the original end-user, with a maximum of 66 months from the Victron Energy invoice date. Exceptions on this are: lead-acid batteries: 2 years from date of purchase by the original end-user, with a maximum of 30 months from the Victron Energy invoice date, Lithium batteries: 3 years from date of purchase by the original end-user, with a maximum of 42 months from the Victron Energy invoice date. In addition to this, proof of correct battery usage is required when making a battery warranty claim.

For a 10% surcharge on the current net price for products that came with a 5-year warranty, an additional 5 years of warranty can be purchased by Victron’s direct customers, bringing the total warranty to 10 years. Warranty extensions need to be applied for ultimately one year before the expiration of the original term. Victron may ask proof that the product was still functional at the time of purchase of the extended warranty.

During the warranty period, Victron Energy will, at its discretion, repair, replace or (partly) credit the defective product free of charge. The warranty does not include performing or reimbursing de‐installation, transportation, and re‐installation.

This warranty will be considered void if the unit has suffered any physical damage or alteration, either internally or externally, and does not cover damages arising from improper use like:

  • Reversed battery polarity.
  • Inadequate connection.
  • Mechanical shock or deformation.
  • Contact with liquid or oxidation by condensation.
  • Use in an inappropriate environment (dust, corrosive vapour, humidity, high temperature, biological infestation, etc.).
  • Breakage or damage due to lightning.
  • Connection terminals and screws destroyed or other damages, like overheating, due to insufficient tightening.
  • For any electronic breakage except due to lightning (reverse polarity, over‐voltage due to external cause), the state of the internal control diode and/or the input/output X and Y capacitors determine the warranty.

This warranty will not apply where the product has been misused, neglected, improperly installed, or repaired by anyone other than Victron Energy or one of its authorized Repair Centres. In order to qualify for the warranty, the product must not be disassembled or modified.

This warranty and our warranty obligations thereunder (repair, replacement or credit) are the direct customer’s and, if applicable, the end-user’s sole rights and remedies and our sole obligations with respect to any defective and/or non-conforming product or breach of warranty and is subject to and without prejudice to the limitations of liability in this warranty.

Victron Energy shall not be liable for damages, whether direct, incidental, special, or consequential, even caused by negligence or fault.

As a product requires service, it must be brought back to the place of purchase. In case no contact can be made with the merchant, or if he is either unable or not allowed to provide service, direct contact should be made with Victron Energy through the support section on Victron’s website.

In case Victron Energy replaces a product, it will own the replaced product. Victron Energy owns all parts removed from repaired products. Victron Energy uses new or reconditioned parts made by various manufacturers when performing warranty repairs or building replacement products.

If Victron Energy repairs or replaces a part of a product, its warranty term is not extended: the warranty will apply for the remaining term of the original warranty term. For example, if Victron Energy replaces a product with a 5-year warranty after 3 years, the warranty of this product will apply for another 2 years, with a minimum of 6 months.

All remedies and the measure for damages are limited to the above. Victron Energy shall in no event be liable for consequential, incidental, contingent or special damages, even if having been advised of the probability of such damages.

The foregoing limited warranty provided by Victron Energy is in lieu of any other warranties, express or implied arising by law, course of dealing, course of performance, usage of trade or otherwise, of any kind whatsoever including, without limitation, warranties of merchantability or fitness for a particular purpose, with respect to any product. The above is without prejudice to the arrangement for consumers detailed above.

Life Support Policy

As a general policy, Victron Energy does not recommend the use of any of its products in life support applications where failure or malfunction of Victron Energy's product can be reasonably expected to cause the failure of the life support device or to significantly affect its safety or effectiveness. Victron Energy does not recommend the use of any of its products in direct patient care. Victron Energy will not knowingly sell its products for use in such applications unless it receives in writing assurances satisfactory to Victron Energy that the risks of injury or damage have been minimized, the customer assumes all such risks, and the liability of Victron Energy is adequately protected under the circumstances.

Warranty on repairs for products outside their warranty period

The warranty period on products that are outside their warranty period and have been repaired by Victron Energy or one of the Victron Energy Repair centres is six (6) months from delivery. The same applies to spare parts and circuit boards that have been supplied or repaired by Victron Energy.

Transport

It is the responsibility of the sender to sufficiently package these products. The transport must be organized in a way to avoid any damage, especially when a single unit or heavy unit is sent.

Severability

If a part of the terms and conditions of this warranty is held invalid, void or unenforceable due to any particular national or international legislation, it shall not affect other parts of the terms and conditions of this warranty.

Applicable law

This warranty is exclusively governed by the laws of the Netherlands, to the exclusion of the UN Convention on Contracts for the International Sale of Goods.

Contact details

Victron Energy B.V. | De Paal 35, 1351 JG Almere, The Netherlands | https://www.victronenergy.com/support
