Victron 12/24/48V 60A BlueSolar MPPT 150/60-Tr Non-Bluetooth Solar Charge Controller
Victron 12/24/48V 60A BlueSolar MPPT 150/60-Tr Non-Bluetooth Solar Charge Controller
98% Peak Efficiency, Advanced Shading MPPT, 60A Output, VE.Direct
Highlights:Model Designation: MPPT 150/60-Tr BlueSolar charge controller identifying voltage and current limits,Status Indicators: Clear LEDs for Bulk, Absorption, and Float charging stage monitoring,Voltage Ratings: Supports 12V, 24V, 36V, and 48V battery systems with 150V maximum PV input,Enclosure Rating: IP43 rated enclosure for protection against water spray and small tools,Wiring Terminals: Large screw terminals for secure connection of battery and solar PV cabling.
Perspective view highlighting the heavy-duty screw terminals for secure cable entry and the large integrated aluminium heat sink for efficient passive cooling.
Availability:
In Stock at Victron Warehouse
Allow up to 5 days before dispatch
View all products from Victron
Guaranteed Safe and Secure Checkout
0
DESCRIPTION
Victron BlueSolar MPPT 150/60-Tr: High-Performance Solar Charge Controller for 12V, 24V, and 48V Systems
Advanced MPPT Technology for Maximum Energy Harvest
The Victron BlueSolar MPPT 150/60-Tr is engineered to extract the maximum available power from your solar array, even under challenging conditions. Its ultra-fast Maximum Power Point Tracking (MPPT) algorithm continuously adjusts to changing light intensity, delivering up to 30% more energy compared to traditional PWM controllers and up to 10% more than slower MPPT designs. This is particularly beneficial during cloudy or rapidly changing weather, ensuring your batteries receive a consistent and optimised charge.
In partial shading scenarios, where multiple power peaks can occur on the PV curve, conventional controllers often lock onto a local rather than the true maximum power point. The BlueSolar MPPT 150/60-Tr employs an advanced detection algorithm that always identifies and tracks the optimal MPP, maximising energy yield even when panels are partially shaded. This capability is critical for installations where shading from trees, masts, or other structures is unavoidable.
Exceptional Efficiency and Robust Design
With a peak conversion efficiency exceeding 98%, the BlueSolar MPPT 150/60-Tr minimises energy losses and operates without a cooling fan, relying on a large aluminium heatsink for silent, maintenance-free thermal management. It delivers full rated charge current up to 40°C, making it suitable for the demanding Australian climate. The controller supports 12V, 24V, and 48V battery systems (with 36V selectable via software), providing flexibility for a wide range of off-grid and mobile applications.
Comprehensive electronic protection safeguards your investment: over-temperature protection with power derating, PV short circuit and reverse polarity protection, and PV reverse current blocking prevent damage from common installation faults. An internal temperature sensor automatically adjusts absorption and float voltages, ensuring correct charging across varying ambient conditions.
Flexible Charging and Monitoring
The charge algorithm is fully programmable via Victron's software, and eight pre-programmed battery presets are selectable via a rotary switch for quick setup. For real-time data visualisation, the controller features a VE.Direct port compatible with the VE.Direct to Bluetooth Low Energy dongle (sold separately) for smartphone monitoring, or the ColorControl panel for advanced system integration.
Note: This model does not include built-in Bluetooth; for integrated wireless connectivity, consider the SmartSolar MPPT range.
Key Features
- Ultra-fast MPPT algorithm for up to 30% more energy harvest versus PWM
- Advanced shading detection locks onto the true maximum power point
- 98% peak efficiency with fanless, silent operation
- Supports 12V, 24V, and 48V battery banks (36V via software)
- 150V maximum PV open circuit voltage for flexible string sizing
- 60A rated charge current for substantial solar arrays
- VE.Direct port for optional Bluetooth dongle or ColorControl panel
- Comprehensive electronic protection and temperature compensation
Built for Australian Conditions
The BlueSolar MPPT 150/60-Tr is designed to withstand harsh environments. Its IP43-rated electronics enclosure protects against water spray and small tools, while the IP22 connection area ensures safe wiring. The robust screw terminals accept up to 35 mm² (AWG2) cable, providing secure, low-resistance connections for both PV and battery circuits. With a wide operating temperature range of -30°C to +60°C, this controller is ready for everything from coastal marine installations to remote outback systems.
Whether you're upgrading an existing off-grid setup, building a new caravan solar system, or managing a remote telecommunications site, the Victron BlueSolar MPPT 150/60-Tr offers reliable, efficient charge control backed by Victron's reputation for quality and durability.
Take Control of Your Solar Harvest
Equip your system with the Victron BlueSolar MPPT 150/60-Tr and experience the difference that advanced MPPT technology makes. Order today to maximise your solar investment with a controller built for performance and longevity.
SPECIFICATIONS
Specifications
| Battery Voltage | 12 / 24 / 48 V Auto Select (Software Tool Needed to Select 36 V) |
|---|---|
| Rated Charge Current | 60 A |
| Nominal PV Power, 12 V | 860 W |
| Nominal PV Power, 24 V | 1720 W |
| Nominal PV Power, 48 V | 3440 W |
| Max. PV Short Circuit Current | 50 A |
| Maximum PV Open Circuit Voltage | 150 V Absolute Maximum Coldest Conditions; 145 V Start-up And Operating Maximum |
| Maximum Efficiency | 98 % |
| Self-consumption | 10 mA |
| Charge Voltage 'Absorption' | Default Setting: 14.4 / 28.8 / 43.2 / 57.6 V (Adjustable) |
| Charge Voltage 'Float' | Default Setting: 13.8 / 27.6 / 41.4 / 55.2 V (Adjustable) |
| Charge Algorithm | Multi-stage Adaptive |
| Temperature Compensation | -16 mV / -32 mV / -64 mV / °C |
| Protection | PV Reverse Polarity / Output Short Circuit / Over Temperature |
| Operating Temperature | -30 to +60 °C (Full Rated Output Up to 40 °C) |
| Humidity | 95 %, Non-condensing |
| Parallel Operation | Yes (Not Synchronized) |
| Colour | Blue (RAL 5012) |
| PV Terminals | 35 mm² / AWG2 (Tr Models) |
| Battery Terminals | 35 mm² / AWG2 |
| Protection Category | IP43 (Electronic Components), IP22 (Connection Area) |
| Weight | 3 kg |
| Dimensions (H x W x D) | 185 x 250 x 95 mm |
| Safety | EN/IEC 62109-1, UL 1741, CSA C22.2 |
| SKU: | Vic-SCC010060200 |
| Barcode: | 8719076025474 |
| Model #: | SCC010060200 |
| MPN: | SCC010060200 |
WARRANTY
Victron Energy Limited Warranty Policy
Direct Customers
Victron Energy provides the following warranty to any direct customer (OEM, distributor or dealer) in relation to any products that Victron Energy has directly sold to the direct customer. This warranty is not an end-user warranty between Victron Energy and an end-user, and end-users shall not have any rights or remedies under this limited warranty towards Victron Energy directly. The direct customer shall, in turn, ensure that the end-user is provided with a warranty identical to this warranty, subject to applicable local mandatory law.
End-Users
Victron Energy may also provide a warranty directly to end-users, in which case the below warranty conditions equally apply to such warranty. In that case, end-users shall claim their warranty at their place of purchase or through the original direct customer of Victron, which can be found through the support section on Victron’s website https://www.victronenergy.com/support. Hence, the direct customer shall on behalf of Victron Energy deal with any warranty claims made under any warranty that Victron Energy may provide directly to end-users. This support section on Victron’s website https://www.victronenergy.com/support will provide further guidance on the procedure for end-users to make a claim under this limited warranty.
If the end-user is a consumer – a natural person who is acting for purposes which are outside that person's trade, business, craft or profession – the following applies. The rights and remedies granted to the consumer under this limited warranty are without prejudice to the consumer’s statutory rights. Furthermore, the consumer is entitled by law to remedies from the seller free of charge in the event of a lack of conformity of the goods (such as repair, replacement, price reduction or rescission), which remedies are not affected by this limited warranty.
Warranty
Victron Energy warrants its products to be free from defects in workmanship and materials for a period of 5 years from the date of purchase by the original end-user, with a maximum of 66 months from the Victron Energy invoice date. Exceptions on this are: lead-acid batteries: 2 years from date of purchase by the original end-user, with a maximum of 30 months from the Victron Energy invoice date, Lithium batteries: 3 years from date of purchase by the original end-user, with a maximum of 42 months from the Victron Energy invoice date. In addition to this, proof of correct battery usage is required when making a battery warranty claim.
For a 10% surcharge on the current net price for products that came with a 5-year warranty, an additional 5 years of warranty can be purchased by Victron’s direct customers, bringing the total warranty to 10 years. Warranty extensions need to be applied for ultimately one year before the expiration of the original term. Victron may ask proof that the product was still functional at the time of purchase of the extended warranty.
During the warranty period, Victron Energy will, at its discretion, repair, replace or (partly) credit the defective product free of charge. The warranty does not include performing or reimbursing de‐installation, transportation, and re‐installation.
This warranty will be considered void if the unit has suffered any physical damage or alteration, either internally or externally, and does not cover damages arising from improper use like:
- Reversed battery polarity.
- Inadequate connection.
- Mechanical shock or deformation.
- Contact with liquid or oxidation by condensation.
- Use in an inappropriate environment (dust, corrosive vapour, humidity, high temperature, biological infestation, etc.).
- Breakage or damage due to lightning.
- Connection terminals and screws destroyed or other damages, like overheating, due to insufficient tightening.
- For any electronic breakage except due to lightning (reverse polarity, over‐voltage due to external cause), the state of the internal control diode and/or the input/output X and Y capacitors determine the warranty.
This warranty will not apply where the product has been misused, neglected, improperly installed, or repaired by anyone other than Victron Energy or one of its authorized Repair Centres. In order to qualify for the warranty, the product must not be disassembled or modified.
This warranty and our warranty obligations thereunder (repair, replacement or credit) are the direct customer’s and, if applicable, the end-user’s sole rights and remedies and our sole obligations with respect to any defective and/or non-conforming product or breach of warranty and is subject to and without prejudice to the limitations of liability in this warranty.
Victron Energy shall not be liable for damages, whether direct, incidental, special, or consequential, even caused by negligence or fault.
As a product requires service, it must be brought back to the place of purchase. In case no contact can be made with the merchant, or if he is either unable or not allowed to provide service, direct contact should be made with Victron Energy through the support section on Victron’s website.
In case Victron Energy replaces a product, it will own the replaced product. Victron Energy owns all parts removed from repaired products. Victron Energy uses new or reconditioned parts made by various manufacturers when performing warranty repairs or building replacement products.
If Victron Energy repairs or replaces a part of a product, its warranty term is not extended: the warranty will apply for the remaining term of the original warranty term. For example, if Victron Energy replaces a product with a 5-year warranty after 3 years, the warranty of this product will apply for another 2 years, with a minimum of 6 months.
All remedies and the measure for damages are limited to the above. Victron Energy shall in no event be liable for consequential, incidental, contingent or special damages, even if having been advised of the probability of such damages.
The foregoing limited warranty provided by Victron Energy is in lieu of any other warranties, express or implied arising by law, course of dealing, course of performance, usage of trade or otherwise, of any kind whatsoever including, without limitation, warranties of merchantability or fitness for a particular purpose, with respect to any product. The above is without prejudice to the arrangement for consumers detailed above.
Life Support Policy
As a general policy, Victron Energy does not recommend the use of any of its products in life support applications where failure or malfunction of Victron Energy's product can be reasonably expected to cause the failure of the life support device or to significantly affect its safety or effectiveness. Victron Energy does not recommend the use of any of its products in direct patient care. Victron Energy will not knowingly sell its products for use in such applications unless it receives in writing assurances satisfactory to Victron Energy that the risks of injury or damage have been minimized, the customer assumes all such risks, and the liability of Victron Energy is adequately protected under the circumstances.
Warranty on repairs for products outside their warranty period
The warranty period on products that are outside their warranty period and have been repaired by Victron Energy or one of the Victron Energy Repair centres is six (6) months from delivery. The same applies to spare parts and circuit boards that have been supplied or repaired by Victron Energy.
Transport
It is the responsibility of the sender to sufficiently package these products. The transport must be organized in a way to avoid any damage, especially when a single unit or heavy unit is sent.
Severability
If a part of the terms and conditions of this warranty is held invalid, void or unenforceable due to any particular national or international legislation, it shall not affect other parts of the terms and conditions of this warranty.
Applicable law
This warranty is exclusively governed by the laws of the Netherlands, to the exclusion of the UN Convention on Contracts for the International Sale of Goods.
Contact details
Victron Energy B.V. | De Paal 35, 1351 JG Almere, The Netherlands | https://www.victronenergy.com/support
