Blue Sea 200A 187-Series Panel Mount Thermal Circuit Breaker
Blue Sea 200A 187-Series Panel Mount Thermal Circuit Breaker
SAE J1171 Ignition Protected, Manual Reset & 5/16" (M8) Studs
Regular price
$218.28
Availability:
In Stock at Blue Sea Warehouse
View all products from Blue Sea
Guaranteed Safe and Secure Checkout
0
DESCRIPTION
Heavy-Duty 200A DC Circuit Protection and Manual Switching
The Blue Sea 187-Series 200A Panel Mount Thermal Circuit Breaker delivers dual-purpose functionality by combining high-amperage overcurrent protection with manual switching in a single, compact unit. Engineered specifically for demanding marine, RV, caravan, and off-grid electrical systems, this breaker simplifies your switchboard layout by eliminating the need for separate master switches and inline fuses on primary DC circuits.
Designed to meet stringent safety standards, its SAE J1171 ignition-protected construction ensures safe installation aboard petrol-powered vessels and within enclosed battery or engine compartments. Whether you are protecting heavy-duty windlasses, high-output alternators, inverters, or main battery busbars, this 187-Series breaker provides reliable thermal response against dangerous electrical overloads and short circuits.
Engineered for Safety and High-Current Reliability
Unlike standard unbranded breakers that can suffer from voltage drop, nuisance tripping, or thermal failure under sustained loads, the Blue Sea 187-Series is built for long-term durability in harsh Australian conditions. It features a mechanical trip-free design, meaning the internal contacts cannot be manually held in the closed (ON) position while a fault current is present. This critical safety mechanism reduces the risk of wire insulation melting or electrical fires during an unresolved short circuit.
The high-visibility yellow manual reset lever provides immediate visual confirmation of your circuit status, with clearly marked ON, OFF/TRIP, and RESET positions. For flexibility across custom dashboards and power distribution panels, the lever can be oriented for either vertical or horizontal operation.
- Dual Functionality: Combines reliable 200A thermal overcurrent protection and manual ON/OFF circuit isolation in one device.
- SAE J1171 Ignition Protected: Safe for installation in petrol engine compartments and marine bilge areas without risking vapour ignition.
- Trip-Free Safety Mechanism: Prevents the actuator from being forced or held ON during an active electrical fault.
- Heavy-Gauge Cable Support: Equipped with robust 5/16" (Approx. M8) terminal studs and generous housing clearance to accommodate heavy-duty cable lugs and high-torque connections.
- Clean Panel Integration: Recessed mounting holes allow for a neat, flush finish on custom marine dashboards, 4WD canopies, and caravan electrical panels.
- Weatherproof Construction: Sealed against moisture and salt spray ingress to ensure dependable operation in coastal and off-road environments.
Application Guidelines and Installation
This panel-mount circuit breaker is ideal for primary DC power distribution, battery bank isolation, and high-draw auxiliary equipment. The robust 5/16" (Approx. M8) studs ensure low-resistance connections when paired with appropriately sized heavy-gauge battery cables.
Important Application Note: Do not use this thermal circuit breaker as a frequent manual switch where high inrush currents are expected, as repeated switching under heavy surge loads can degrade the internal contact surfaces over time.
Upgrade Your Primary Circuit Protection
Secure your marine vessel, caravan, or off-grid power system with industry-standard circuit protection. Add the Blue Sea 187-Series 200A Panel Mount Thermal Circuit Breaker to your build today for safe, compliant, and streamlined DC power management.
SKU: BS-7049B
SPECIFICATIONS
| Specification | Value |
|---|---|
| Product type | Circuit breaker |
| Mounting / form factor | Panel mount |
| Ignition protected | Yes |
| Actuator type | Manual |
| Terminal size | 5/16 M8 |
| SKU: | BS-7049B |
| Model #: | BS-7049B |
| MPN: | BS-7049B |
| HS code: | 8536200040 |
| Country of origin: | MX |
| Package weight: | 0.3 kg |
| Package length: | 0.15 m |
| Package width: | 0.1 m |
| Package height: | 0.09 m |
WARRANTY
Blue Sea Warranty Policy
Blue Sea Systems products sold by us are supplied with a warranty against defects for the warranty period shown below, subject to the product type, application and the terms of this warranty policy.
The express warranty provided by us is limited to a maximum of 5 years from the original date of purchase, unless otherwise required under Australian Consumer Law.
Blue Sea Systems may offer longer manufacturer support on some products at their discretion
Warranty Lengths by Product Range
| Blue Sea Product Range | Warranty Length | Application / Notes |
|---|---|---|
| Most Blue Sea Systems Products | 5 years | Applies to most Blue Sea Systems products found to be defective in materials or manufacture. |
| P12 Battery Chargers | 5 years | Warranty period starts from the original date of purchase. |
| P12 Remote Displays | 5 years | Warranty period starts from the original date of purchase. |
| Digital Meters | 3 years | Warranty period starts from the original date of purchase. |
| Vessel System Monitors | 3 years | Warranty period starts from the original date of purchase. |
Warranty Assessment and Remedy
If a Blue Sea Systems product is found to be defective in materials or manufacture within the applicable warranty period, we will, at our discretion, arrange a repair, replacement, store credit or refund, depending on the nature of the fault and the requirements of Australian Consumer Law.
Products may need to be returned for assessment before a warranty claim can be approved. Where required, the product must be returned with dated proof of purchase and a clear description of the fault.
Labour costs for removing, replacing, reinstalling or diagnosing a product are not covered by this express warranty unless otherwise required under Australian Consumer Law.
Making a Warranty Claim
To make a warranty claim, please contact us with your dated proof of purchase, product details and a description of the fault.
The product may need to be returned for inspection before the claim can be assessed. If the product is confirmed to be faulty and covered by this warranty, we will advise the available remedy.
What This Warranty Does Not Cover
This warranty does not cover faults or damage caused by incorrect installation, incorrect application, misuse, abuse, neglect, unauthorised modification, accidental damage, normal wear and tear, environmental damage, or failure to use the product in accordance with the manufacturer's instructions.
- Incorrect installation or wiring
- Incorrect product selection or application
- Misuse, abuse or neglect
- Physical or accidental damage
- Water ingress or environmental damage outside the product's intended use
- Unauthorised modification or repair
- Normal wear and tear
- Labour costs for removal, replacement, reinstallation or diagnosis
- Freight, travel or call-out costs unless otherwise required by law
- Products not returned for assessment when reasonably required
Manufacturer Support
Blue Sea Systems may provide additional manufacturer support on some products beyond the warranty period listed above. Where available, we may assist customers in contacting the manufacturer, but any manufacturer support beyond the express warranty period is subject to the manufacturer's own terms and continued availability.
Australian Consumer Law
This warranty is in addition to other rights and remedies available at law. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
