Blue Sea 150A 187-Series Panel Mount Thermal Circuit Breaker
Blue Sea 150A 187-Series Panel Mount Thermal Circuit Breaker
Up to 48V DC, Ignition Protected, Trip-Free & 5/16" (M8) Studs
Regular price
$167.82
Availability:
Special Order
View all products from Blue Sea
Guaranteed Safe and Secure Checkout
0
DESCRIPTION
Heavy-Duty 150A DC Circuit Protection and Manual Switching
The Blue Sea 187-Series 150A Panel Mount Thermal Circuit Breaker delivers dual-function utility by combining reliable overcurrent protection and manual on/off switching into a single, compact device. Engineered for demanding 12V, 24V, and up to 48V DC electrical systems, this heavy-duty breaker eliminates the need for separate fuse holders and battery switches, simplifying your wiring topology and saving valuable installation space in marine vessels, 4WDs, caravans, and off-grid power setups.
Unlike standard auto-grade breakers that can suffer from nuisance tripping, premature mechanical wear, or dangerous arcing under load, the Blue Sea 187-Series is built to strict marine-grade standards. Its robust housing and precision internal mechanisms ensure accurate thermal response to overloads and short circuits, safeguarding expensive cabling, inverters, and auxiliary battery banks from thermal damage and electrical fire risks.
Engineered for Safety: Ignition Protected and Trip-Free
When installing high-amperage DC protection in confined spaces or marine engine compartments, safety is paramount. This 150A thermal circuit breaker is fully ignition protected, making it safe for installation aboard petrol-powered boats and near battery banks where explosive gases may accumulate. Furthermore, the internal mechanism features a failsafe "trip-free" design. In the event of a fault current condition, the breaker will trip and cannot be manually held in the "on" position, preventing operators from overriding the safety mechanism until the underlying electrical fault is resolved.
Key Features and Benefits
- Dual-Function Design: Combines heavy-duty 150A circuit protection with manual on/off switching in one unit, reducing connection points and voltage drop.
- Trip-Free Mechanism: Ensures the circuit breaker cannot be forced or held closed during an active fault condition, protecting wiring and connected equipment.
- High-Visibility Manual Lever: The contrasting yellow actuator clearly indicates trip status and allows for easy manual disconnection, visible in either vertical or horizontal mounting orientations.
- Heavy-Duty Terminal Studs: Equipped with robust 5/16" (Approx. M8) tin-plated copper studs that provide high-torque connections and generous clearance for heavy-gauge cable lugs.
- Ignition Protected: Certified safe for installation in marine engine rooms and compartments on petrol-powered vessels.
- Clean Panel Integration: Recessed mounting holes offer a flush, professional appearance on switchboards, bulkheads, and custom electrical panels.
Application Considerations and Best Practices
Designed for systems up to 48V DC maximum, the Blue Sea BS-7048B is ideal for main DC feed protection, high-output alternator charging circuits, DC-to-DC chargers, and windlass or winch isolation. The large 5/16" (Approx. M8) terminal studs easily accommodate the substantial cable lugs required to carry 150A safely, minimising resistance and heat build-up at the termination point.
Important Application Note: While this unit functions as a manual disconnect switch for maintenance and isolation, do not use this breaker as a regular switch where high inrush currents are expected (such as repeatedly switching un-precharged inverter capacitors under load), as this can accelerate contact wear over time.
Upgrade Your DC Electrical Safety
Equip your marine, caravan, or off-grid 12V to 48V power system with industry-leading overcurrent protection. Add the Blue Sea 187-Series 150A Panel Mount Thermal Circuit Breaker to your setup today for dependable, marine-grade circuit management.
SKU: BS-7048B
SPECIFICATIONS
| Specification | Value |
|---|---|
| Product type | Circuit breaker |
| Mounting / form factor | Panel mount |
| Switching logic | Manual |
| Switching function | On/off |
| Actuator type | Manual lever |
| Terminal size | 5/16 in (M8) |
| Ignition protected | Yes |
| SKU: | BS-7048B |
| Model #: | BS-7048B |
| MPN: | BS-7048B |
| Package weight: | 0.24 kg |
| Package length: | 0.09 m |
| Package width: | 0.06 m |
| Package height: | 0.08 m |
