Votronic Tank Level Sensor Electrode 15-50K for Fresh, Grey, Black 5545
Votronic Tank Level Sensor Electrode 15-50K for Fresh, Grey, Black 5545
Level measuring of fresh, grey and black water
Highlights:Measuring Rods: Two rods that can be shortened to suit tank heights between 15cm and 50cm,Adjustment Dial: Integrated rotary dial for setting the water depth and full-scale calibration,Mounting Flange: Threaded PG 29 mounting flange for secure installation to the tank wall,Connection Cable: 3-pin pre-wired 50cm connection cable for 12V or 24V systems.
Close-up showing the tank level sensor installed using the inside mounting method where the nut and flange sit on top of the tank wall.
Close-up showing the tank level sensor installed using the outside mounting method where the threaded body is inserted from within the tank.
Key features: Adjustable for tank heights between 15cm and 50cm, Linear continuous level signal output for 12V and 24V operation, IP 67 sealed electronic system, Reverse battery and overload protection, Suitable for fresh, grey, or black water in plastic and metal tanks.
Regular price
$109.00
Availability:
In Stock
View all products from Votronic
Guaranteed Safe and Secure Checkout
3
DESCRIPTION
For precise level measuring of fresh water, grey water or toilet water in metal or plastic tanks. Combined with the display it provides precise level measurement information. Stick can be easily cut to tank height. The measured value is sensed electronically and the signal sent to the display unit via 2 cables. Included: Tank electrode, packing ring, nut PG 29, connection cable 75cm and manual. Possibility to install the tank electrodes from inside as well as from outside on the tank top. In case of fresh water tanks, the installation is also possible at the tank bottom. Insensitive to soiling and deposits in water; No mechanical moving parts; Robust fully-electronic capacitive measuring method. The electronic system (IP 67) is sealed and frost-proof, so is suitable for problematic locations, such as at underfloor tanks. All Votronic measuring sensors work with the capacitive measuring method and independently of pressure. Therefore, a falsification of the measured values in case of overpressure in the tank, pressure filling etc. is avoided. They includes a protection against reverse battery, overvoltage, short-circuit and overload.
SKU: Vot-5545
SPECIFICATIONS
| SKU: | Vot-5545 |
| Barcode: | 4250683602770 |
| Model #: | Vot-5545 |
| MPN: | Vot-5545 |
WARRANTY
We are liable for material defects of all our products within 36 months from the purchase date against representation of the sales slip or of the invoice, proper handling, intended use and consideration of the installation and operating manual provided. If the buyer or third execute modification and repair tasks to the product (external intervention) or will the electronic or the entire product damaged by moisture, any claims for defects for these tasks and the results being involved will be void. Claims will also be void for any service being performed by third, which has not been ordered by us in writing. Service is exclusively allowed to be performed by Votronic GmbH & Co. KG Lauterbach.
