Genasun 8A MPPT 36V Voltage Boost (Lead-Acid) - Waterproof Solar Charge Controller
Genasun 8A MPPT 36V Voltage Boost (Lead-Acid) - Waterproof Solar Charge Controller
Made in USA - 5 year warranty - IP68
Highlights:LED Status Indicator: Multicolour LED indicates standby, charging, full battery, or error states,Wiring Guide: Clear connection guide for battery and solar panel inputs printed on the face,Mounting Flange: Integrated mounting holes for secure installation on vehicles or enclosures.
The fully encapsulated IP68 housing protects internal electronics from water and dust, making it suitable for harsh outdoor environments.
Standard wiring configuration showing PV input, 10A in-line fuse protection, and connection to three 12V batteries in series for a 36V system.
Application example showing the controller integrated into an electric golf cart to boost solar panel voltage for the 36V drive battery.
Key features: Fast MPPT tracking (15 times/second), Waterproof IP68 rating, Voltage boost technology for e-vehicles, Made in the USA, Operating range -40°C to 85°C.
Regular price
$265.00
Availability:
In Stock
View all products from Genasun
Guaranteed Safe and Secure Checkout
5
DESCRIPTION
GVB-8-WP (BOOST) 8A MPPT
Reliability & efficiency down to a science.
Marine | RV | Industrial | Military | Street Lighting | Off-Grid
Get your money’s worth with Genasun. A true problem-solver, the unique GVB charge controller with MPPT allows a lower-voltage solar panel to charge higher-voltage batteries. Want to charge a 24V battery with a 48-cell solar panel? No problem. A 48V battery from a 12V panel? We’ve got you covered. With 99% peak efficiency, they are the industry’s most efficient voltage-boosting controllers. True MPPT delivers consistent performance, unlike the “Nominal MPPT” of competitors. The advanced electronics inside the controller are encased in a proprietary potting compound making them ideal for golf-cart, marine, and vehicle applications.
- Waterproof
- 99% peak efficiency
- In-line fuse
- Ultra-fast true MPP Tracking
- Excellent low-light performance
- Wire leads for easy installation
SPECIFICATIONS
.jpg)
| SKU: | GVB-8-Pb-36V-WP |
| Model #: | GVB-8-Pb-36V-WP |
| MPN: | GVB-8-Pb-36V-WP |
WARRANTY
The GV-Boost Waterproof solar charge controllers carry a 5-year warranty on materials and workmanship. Genasun's warranty does not cover damage due to abuse or operation beyond the rated specifications.
