Solar to power Gantry crane at Kununurra

Date Posted:20 July 2018



Solar 4 RVs has designed and assembled a solar system for a new gantry crane to be installed in mid-2019 at Kununurra.



Solar system designed for gantry crane at Kununurra



The system design for the solar panel installation took sun angles and shading into consideration whilst the componentts are installed into a weatherproof box that is accessible for maintenance and monitoring.



The image below shows the equipment box with solar charge controllers and other electronic and monitoring equipment required for the solar system.

Solar system equipment and monitoring units are installed into waterproof unit



The Kununurra & the Ord irrigation area is currently undertaking a $4.1 million project to install a new gantry crane at the Kununurra Diversion Bridge.  The Kununurra Diversion Dam Travelling Gantry Crane permanently straddles the Victoria Hwy, a major traffic route between Western Australia and the Northern Territory.

Key Crane Features:

  • Solar Power System
  • Main Hoist Capacity: 2 x 10 tonne hoists
  • Auxiliary Hoist: 3.2 tonne with personnel rated capacity
  • Water Wash Down System for crane and dam use
  • On-board generator



The image below shows the old gantry crane which will be replaced.

Gantry crane which will be replaced at Kununurra by Vector Lifting
